Product Details:
Payment & Shipping Terms:
|
| Cut Capacity W*H (mm): | Round 300 | Saw Belt Size(mm): | 3620*27*0.9 |
|---|---|---|---|
| Selt Line Speed(m/min): | 40/60/80 | Main Generator Power(kw): | 3kw |
| Hydraulic Generator Power(kw): | 0.75kw | Cooling Generator Power (kw): | 0.04kw |
| Packing Dimensions(mm): | L*M*H 1750*2200*1450 | Weights Of Machine (kgs): | 700kgs |
| High Light: | 40m/Min Angle Sawing Machine,300mm Angle Sawing Machine,horizontal metal bandsaw machine |
||
China specializing in cutting metal diameter 300mm 60 degrees 90 degrees 45 degrees Angle sawing machine
Horizontal band sawing machine is mainly used for cutting alloy structural steel, medium carbon steel, low alloy steel, heat resistant touch steel SKT, high alloy steel, special alloy steel and stainless steel, bearing steel, acid-resistant steel, straightening steel and other metal materials.
According to the requirements of the cutting Angle into Angle sawing machine (can sawing Angle of 90 degrees 45 degrees) no Angle that is 90 degrees vertical cutting. 1. Adjustment of the cutting Angle: if you want to cut any Angle within a 45-degree Angle, first loosen the fixed handle, then push the saw bow clockwise and align it with the Angle scale you need on the Angle scale on the seat, then lock the fixed handle. 2. When you adjust the sawing Angle, the Angle of the vice shall be adjusted to loosen the vice fixing screw, and then push the vice into the vice to make the vice and the vice have the same Angle, and then lock the fixing screw.
| Type | G-300 |
| Cut capcity W*H (mm) | round 300 |
| square 700*600 | |
| Bundle cutting W*H (mm) | Max.200*90 |
| Min.100*20 | |
| Saw belt size(mm) | 3620*27*0.9 |
| belt line speed(m/min) | 40/60/80 |
| Main generator power(kw) | 3 |
| Hydraulic generator power(kw) | 0.75 |
| Cooling generator power (kw) | 0.04 |
| Working clamp style | Hydraulic |
| Saw belt tighten style | Hand |
| Main trasmit structure | Turbine |
| Loading style | Extra roller |
| Packing dimensions(mm) L*M*H | 1750*2200*1450 |
structural features :
The main components of China specializing in cutting metal diameter 300mm 60 degrees 90 degrees 45 degrees Angle sawing machine manufacturer are: bottom seat; A bed and a column; Saw beam and transmission mechanism; Guide device; Workpiece clamping; Tensioning device; Feeding; Hydraulic transmission system; Electrical control system; Lubrication and cooling system.
The hydraulic transmission system consists of a hydraulic loop composed of pumps, valves, oil cylinders, oil tanks, pipelines and other auxiliary parts. Under the electrical control, the lifting of the saw beam and the clamping of the workpiece are completed. Through the speed regulating valve can be implemented in the feed speed stepless, to achieve the sawing of different materials workpiece needs.
The electrical control system is composed of electrical box, control box, junction box, travel switch, electromagnet, etc., which is used to control the rotation of the saw blade, the lifting of the saw beam, the clamping of the workpiece, etc., so as to realize the normal cutting cycle according to a certain working procedure.
Lubrication system must be lubricated according to the requirements of the lubrication parts of the machine (wire brush shaft, worm box, active bearing, worm bearing, up and down shaft of lifting cylinder, clamping screw rod on the sliding surface of the movable vice) before starting up. The worm gear and worm gear in the worm gear box are lubricated by no. 30 oil bath, which is injected by the oil plug hole in the upper part of the worm gear box. The oil mark is provided on the head of the box. After trial for one month, oil should be changed. After that, oil should be changed every 3-6 months. The lower part of the worm gear box is equipped with oil drain plug.
China specializing in cutting metal 60 degrees 90 degrees 45 degrees Angle sawing machine main feature:
Cutting speed hydraulic control, stepless speed regulation;
Guide block structure scientific and reasonable, prolong the service life of saw blade;
Double column structure, stable operation;
Stable sawing, high precision;
The work clamping adopts hydraulic clamping, easy to operate.
