PLC Induction Pipe Bending Machine Medium Frequency Power Source IGBT Control System

China PLC Induction Pipe Bending Machine Medium Frequency Power Source IGBT Control System supplier
PLC Induction Pipe Bending Machine Medium Frequency Power Source IGBT Control System supplier PLC Induction Pipe Bending Machine Medium Frequency Power Source IGBT Control System supplier PLC Induction Pipe Bending Machine Medium Frequency Power Source IGBT Control System supplier PLC Induction Pipe Bending Machine Medium Frequency Power Source IGBT Control System supplier

Large Image :  PLC Induction Pipe Bending Machine Medium Frequency Power Source IGBT Control System

Product Details:

Place of Origin: Cangzhou,Hebei,China
Brand Name: Heiyan
Certification: ISO,CE,SGS,BV
Model Number: KGPS-200KW

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: 3000 USD
Packaging Details: Packaging Details Packed in wooden cases
Delivery Time: 10-30 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: 30 Sets per Month
Contact Now
Detailed Product Description
Product Name: Plc Induction Pipe Bending Machine Medium Frequency Power Source Power Source: Electric
Voltage: 380v Cooling: Water
Application: Heating, Forging, Melting, Hardening And Etc Work Condition: Continuously For 24 Hours
System: IGBT Control Condition: New
Warranty: 24 Months After-sales Service Provided: Engineers Available To Service Machinery Overseas

Plc Induction Pipe Bending Machine Medium Frequency Power Source





Production Description of Plc Induction Pipe Bending Machine Medium Frequency Power Source



The product is suitable for casting industry, mainly used for smelting cast iron, carbon steel, high manganese steel, gray iron, ordinary scrap iron, alloy steel, non-ferrous metal (such as: copper, aluminum, silicon, etc.) and metals.The furnace body used is GW0.15t-0.20t.Best (note: aluminum housing, stainless steel housing, magnetic yoke steel housing).The selected customer factory must choose power transformer capacity range: 250KVA-315KVA. The failure rate is small, the maintenance is simple, the price is low and the durability is long.And get the plant going again.The power factor of this product reaches above 0.85 when running at full load.Please consult our sales staff before you choose this product.Only after knowing your usage and the actual situation of your factory can we select the best products for you.



Technical specification of Plc Induction Pipe Bending Machine Medium Frequency Power Source

Power Input Power Output Power Cool Water Cooling Out-Dimension Weight
Model (V) (KW) (T/h) Water Pressure (mm)(L×W×H) (KG)
        (Mpa)
KGPS60 380 60 2.5 0.25 A750×800×1980 400
KGPS100 380 100 3 0.25 A750×800×1980 480
KGPS160 380 160 5 0.3 B750×800×1980 600
KGPS250 380 250 5 0.3 B-1400×800×1980 700
KGPS400 380 400 6 0.4 C-1800×800×1980 850
KGPS500 380 500 6 0.4 C-1800×800×1980 1000
KGPS750 380 750 8 0.4 C-1800×800×1980 1250
KGPS1000 380 1000 10 0.4 D-2200×800×2100 1250
KGPS1500 380 1500 12 0.4 E-3600×800×2100 1750
KGPS2000 380 2000 18 0.4 E-3600×800×2100 2000
KGPS2500 380 2500 20 0.4 E-3600×800×2100 2500
KGPS3200 380 3200 35 0.4 E-3600×800×2100 2800
KGPS6500 380 6500 50 0.4 F-5200×800×2100 3500
Other customized specifications are welcomed.



Medium Frequency Power Sourse for Heating Induction Equipment



Features of Plc Induction Pipe Bending Machine Medium Frequency Power Source:

1) Wide frequency tracking range:0.2kHz-600kHz


2) The load adaptation range is wide : series resonance is not afraid of no load , parallel resonance is not afraid of heavy load


3) Intelligent protection function: power regulation range 1%-100%, superior to most domestic manufacturers.


4) Intelligent protection function: with overvoltage, overcurrent, overfrequency, overheating, leakage and other restrictive protection functions, but also with water pressure, lack of phase, short circuit and other conventional hardware protection functions, all faults can be remembered

5)adopt Rital cabinet , equipped with IP54 protection grade and equipped with industrial temperature and humidity adjustment air conditioning,signal transmission by optical fiber to effectively avoid the temperature, humidity, electromagnetic interference caused by power fluctuations and faults.



6)100% success rate of startup: 100% success rate of starting equipment under any working condition


7)High startup speed: equipment startup to maximum power stable output time less than 0.15 seconds, much faster than traditional equipment startup time of 1-2 seconds


8)Good repetition consistency: all digital power control, Power resolution can be achieved 0.25‰,through the touch screen directly input set power, can avoid the traditional equipment with analog potentiometer to adjust the power caused by power fluctuations


9)Multifunctional extended interface: easy to connect with machine tool production line and digital communication interface, can realize centralized control of industrial field.



Advantages of our Plc Induction Pipe Bending Machine Medium Frequency Power Source:

Plc Induction Pipe Bending Machine Medium Frequency Power Source



1. Big reactor design:

Strong filtering ability, greatly reduce harmonic pollution to the grid, suppress the current mutation, protect the transformer.

2. Large section area of current carrying discharge:

Select 8×60 copper row, large cross-sectional area, strong current carrying capacity, reduce heat.

3. Cabinet uses RITTAL brand:

Durable and beautiful

4. Appliances: SCHNEIDER brand

5. Button: IDEC brand

6. Insulating plate:Durable and high insulation grade, beautiful

7. Water segregator: Stainless steel

8. Cooling water pipe: Specially customized, high temperature and high pressure

9. Inverter increase resistance and capacity absorption: it can effectively suppress the instantaneous oscillation and high-frequency current of operating overvoltage, so that the waveform of overvoltage becomes slow, the steepness and amplitude are reduced, plus the damping effect of resistance, so that the high frequency oscillation rapidly attenuates



Plc Induction Pipe Bending Machine Medium Frequency Power Source





RFQ of Our Plc Induction Pipe Bending Machine Medium Frequency Power Source:

Q1.How does your factory perform quality control?
A :the selection of international and domestic a line brand, strict control of assembly process, each machine before delivery, and by experiments in the simulation field 24 hours of continuous work,ensure that qualified factory every device.
Q2. What about after-sales service?
A :(1) the after-sales hotline is 24 hours online;
(2) simple problems can be video or mail processing;
Q3. Why do you choose our Heiyan
Plc Induction Pipe Bending Machine Medium Frequency Power Source?
A :(1) we are a manufacturer specializing in the production of induction heating equipment in China. We are a comprehensive enterprise integrating r&d, production and sales.We not only produce induction heating equipment, but also provide customers with the overall solution of frequenching, welding and forging.
(2) We have a senior team in the induction heating industry for over 15 years.
