|Product Name:||Energy Saving Medium Frequency Power Supply Heating Induction Equipment||Work Condition:||Continuously For 24 Hours|
|Fter-sales Service Provided:||Online Support, Field Installation, Commissioning And Training, Video Technical Support, Engineers Available To Service Machinery Overseas||Usage:||Melting Furnace, Melting ,iron, Steel,copper, Aluminum|
|Power Source:||Electric||Working Voltage3:||Phase , 380V±5%, 50/60HZ|
|Market:||South East Asia, Africa, Middle East, South America Etc.||Cooling:||Water Cooling|
|Application:||Manufacturing Plant, Heating, Forging, Energy,Melting, Hardening And Etc||Warranty:||24 Months|
power supply unit,
medium frequency power supply
Energy Saving Medium Frequency Power Supply Heating Induction Equipment
Production Description of our Energy Saving Medium Frequency Power Supply Heating Induction Equipment:
The product is suitable for casting industry, mainly used for smelting cast iron, carbon steel, high manganese steel, gray iron, ordinary scrap iron, alloy steel, non-ferrous metal (such as: copper, aluminum, silicon, etc.) and metals.The furnace body used is GW0.15t-0.20t.Best (note: aluminum housing, stainless steel housing, magnetic yoke steel housing).The selected customer factory must choose power transformer capacity range: 250KVA-315KVA. The failure rate is small, the maintenance is simple, the price is low and the durability is long.And get the plant going again.The power factor of this product reaches above 0.85 when running at full load.Please consult our sales staff before you choose this product.Only after knowing your usage and the actual situation of your factory can we select the best products for you.
The Specification of our Energy Saving Medium Frequency Power Supply Heating Induction Equipment:
|Model||Power Input||Power Output||Usage|
|Inlet line Voltage (V)||Inlet Currency||Frequency||Power Rate|
|3 phases or 6 phases||(A)||(KW)|
|KGPS-100||380||160||1--8||100||Surface hardening, heating, melting.|
|KGPS-120||380||200||1--8||120||Surface hardening, heating, melting.|
|KGPS-160||380||260||1--8||160||Surface hardening, heating, melting|
|KGPS-200||380||320||1--8||200||Surface hardening, heating, melting|
|KGPS-250||380||400||1--8||250||Surface hardening, heating, melting|
|KGPS-300||380||480||1--8||300||Surface hardening, heating, melting|
|KGPS-400||380||640||1--4||400||Surface hardening, heating, melting|
|KGPS-500||380||800||0.5--2.5||500||Surface hardening, heating, melting|
|KGPS-750||380||1200||0.5--2.5||750||Surface hardening, heating, melting|
APPLICATIONS of our Energy Saving Medium Frequency Power Supply Heating Induction Equipment:
A. Heating (hot forging, hot fitting and smelting):
B. Heat Treatment (surface quench):
It is mainly aims to change the rigidity of the metal materials through the heat treatment to work pieces. Detail applications are stated as follows:
C. Welding (braze welding, silver soldering and brazing)
It mainly aims to melt the solder by heating it to a certain temperature for the purpose of connecting two types of metals of the same material and different
D. Annealing (tempering and modulation)
The main control circuit board is the core component of the machine.high quality. We have many stocks.
Main control circuit board as the main part of the machine, we made in their research and development, and adopted by the company and built since the automatic welding and testing equipment to ensure that each set of machine can achieve the best effect, and we have main control board in stock lone time, can satisfy the parts supply problems.
Features of the Energy Saving Medium Frequency Power Supply Heating Induction Equipment:
1. Comprehensive protection function
Control system protection measures include:
High grid voltage, low grid voltage, high DC voltage, high thyristor current, high capacitor voltage, high furnace voltage, high operating frequency, high cooling water temperature, low cooling water pressure, low cooling water flow, and electric furnace leakage
2. the control system :Digital inverter control
IF power adopts advanced all-digital control system based on high-performance microcontrollers.
The digital inverter controller is integrated inside the CPU. Using power, voltage, current three closed-loop control algorithm. During normal operation, the voltage, current and power are sent to the CPU through their respective converters. The control software detects these parameters and adjusts the operating frequency to ensure that the output power is always equal to the rated power.
When the empty furnace power transmission (too much impedance) or the frozen furnace power transmission (impedance is too small), control software can automatically call the limiting voltage or current limiting algorithm, limiting the output voltage or current does not exceed the allowable.
The control software has a variety of parameter limiting functions, including: maximum power limit, thyristor current output limit, furnace voltage limit, capacitor voltage limit, maximum and minimum operating frequency limits
The parameters of the control algorithm can be set by the keyboard and they are stored in the EEPROM of the control board. The parameters are easily changed so that half-bridge series inverters are suitable for melting different metals, such as cast iron, copper, aluminum, etc.
The thyristor is a controlled shutdown device. The start-up of the inverter is completely controlled by the trigger pulse, so the inverter can start 100% under any conditions.
Advantages of Our Heiyan Energy Saving Medium Frequency Power Supply Heating Induction Equipment:
1. Energy saving:
The power factor reaches 0.99 under the condition of full power output. The integrated circuit board is adopted and the current and voltage are adjusted internally. The core components are high performance, high density and large-scale ASIC integrated circuit produced in the United States, which are digitized. The rectifier trigger part does not need any adjustment, and has the advantages of high fraud reliability, high pulse symmetry, strong anti-interference ability and fast response speed.
2. Big reactor design:
Strong filtering ability, greatly reduce harmonic pollution to the grid, suppress the current mutation, protect the transformer.
3. Large section area of current carrying discharge:
Select 8×60 copper row, large cross-sectional area, strong current carrying capacity, reduce heat.
4. Cabinet uses RITTAL brand:
Durable and beautiful
5. Appliances: SCHNEIDER brand
6. Button: IDEC brand
7. Insulating plate:Durable and high insulation grade, beautiful
8. Water segregator: Stainless steel
9. Cooling water pipe: Specially customized, high temperature and high pressure
10. Inverter increase resistance and capacity absorption: it can effectively suppress the instantaneous oscillation and high-frequency current of operating overvoltage, so that the waveform of overvoltage becomes slow, the steepness and amplitude are reduced, plus the damping effect of resistance, so that the high frequency oscillation rapidly attenuates.
Please do not touch any exposeed electric components and induction coils when it is starting work .Please close system if repair or moving . Refuse electrocute!
