| Model Number: | HYT | Dimension (L*W*H): | 3050*2550*5800 |
|---|---|---|---|
| Motor Power (KW): | 30KW | Slide Stroke (mm): | 200mm |
| Working Speed: | 10-24mm/s | Nominal Pressure (KN): | 360KN |
| Weight (T): | 200T | After-sales Service: | Field Maintenance And Repair Service |
| High Light: | automatic forming machine,tee forming equipment |
||
2000T cold extruded carbon steel and stainless steel tee forming machine
Tee equipment is mainly able to produce tee pipe fitting equipment, tee machine production of tee mainly have the same diameter and reducing tee, tee shape is divided into T shape and Y shape.Tee machine main production tee material has carbon steel, alloy steel stainless steel and so on.
The main power of the three-way machine is the hydraulic cylinder, the body of the three-way machine belongs to the non-standard products, so there is no specific specifications and models, we can directly customize according to the specific requirements provided by the customer.
| Specification | Unit | HYT-315 | HYT-500 | HYT-1000 | HYT-1500 | HYT-2000 | HYT-4000 | |
| Tee OD range | lnch | 1~4 | 3~6 | 4~8 | 8~12 | 10~16 | 20~28 | |
| Master cylinder |
Normal force | KN | 3150 | 5000 | 10000 | 15000 | 20000 | 40000 |
| Work stroke | mm | 450 | 480 | 610 | 670 | 800 | 1200 | |
| Go down speed | mm/s | 60 | 80 | 80 | 80 | 80 | 80 | |
| Work forward speed | mm/s | 8~12 | 8~12 | 8~12 | 8~12 | 8~12 | 8~12 | |
| Return stroke speed | mm/s | 80 | 100 | 100 | 100 | 100 | 100 | |
| Side cylinder |
Normal force | KN | 3150 | 5000 | 8000 | 12500 | 18000 | 40000 |
| Work stroke | mm | 300 | 320 | 340 | 360 | 410 | 500 | |
| Advance speed | mm/s | 10~15 | 10~15 | 10~15 | 10~15 | 10~15 | 10~15 | |
| Return stroke speed | mm/s | 60 | 60 | 60 | 60 | 60 | 60 | |
| Push-out cylinder |
Normal force | KN | 300 | 400 | 500 | 630 | 1500 | 2000 |
| Work stroke | mm | 300 | 300 | 400 | 450 | 550 | 700 | |
| Workbench effective area |
Right and left | mm | 550 | 750 | 900 | 1200 | 1400 | 1800 |
| Front and back | mm | 400 | 580 | 800 | 1000 | 1200 | 1500 | |
| The max distance from slide block to workbench | mm | 190 | 250 | 370 | 460 | 520 | 650 | |
| Center high of side cylinder | mm | 980 | 1100 | 1350 | 1800 | 1900 | 2500 | |
| Motor power | KW | 30 | 45 | 74 | 110 | 220 | 330 | |
tee machine is mainly oil pump, motor, PLC control box, water tank, the corresponding model mold composition.Tee forming machine body belongs to non-standard products, so there is no detailed specifications and models, we can customize the tee machine according to the customer's request.The diameter of the tee is 21mm-630mm and the wall thickness is 3mm-20mm.Mechanical tee and ordinary tee function difference.Mechanical tee is divided into groove mechanical tee and screw mechanical tee.It can be used to connect branch pipe directly on the steel pipe, and has many applications on the device of fire pipe and spray pipe.In demand for diversion or confluence can be used mechanical tee.Device method first in the steel pipe with a hole opening machine hole, and then the mechanical three card hole, hole by the sealing ring along the wall of the tube.Mechanical tee wire connection and groove type two.When connecting the three mechanical connections, the clearance between the three mechanical connections and holes should be checked.Mechanical tee hole spacing shall not be less than 1m.
